Product Description
Machine is used in metal fabrication industries as it offers precision to bore holes in different sizes on tough metals. Holding a highly reputed and trusted market standing, we are engaged in manufacturing and supplying Radial Drill Machine. Our machine can make holes or drill on metal sheet, bars and panels with ease. We manufacture this machine with the help of our diligent workforce using high quality mild steel and cast iron. Radial Drill Machine has a large geared head which can be moved along with an arm that radiates from the machine's column.
Features:
- High working efficiency
- Easy to operate
- Longer working life
Technical Specifications
|
MODEL NO
|
ORD - 1
|
ORD - 1.2
|
ORD - 1.5
|
ORD - 2
|
Drilling Capacity In Steel
|
25 MM
|
32 MM
|
40 MM
|
50 MM
|
Drilling Capacity In Casting
|
30 MM
|
35 MM
|
45 MM
|
55 MM
|
Tapping Capacity In Casting
|
20 MM
|
25 MM
|
25 MM
|
30 MM
|
Maximum Distance From Spindle To Column
|
24"
|
32"
|
36"
|
48"
|
Minimum Distance From Spindle To Column
|
10"
|
12"
|
12"
|
18"
|
Maximum Distance From Spindle To Base Plate
|
30"
|
34"
|
40"
|
50"
|
Diameter Of Column
|
5.1/2"
|
7"
|
9"
|
10"
|
No. Of Spindle Speeds
|
4 + 4 = 8
|
3 + 3 = 6
|
3 + 3 = 6
|
3 + 3 = 6
|
Range Of Spindle Speeds
|
80-700 RPM
|
80-700 RPM
|
50-760 RPM
|
40-750RPM
|
Working Surface Of Base Plate
|
9"
|
11"
|
12"
|
15"
|
Travel Of Spindle
|
6"
|
8"
|
9"
|
12"
|
Spindle Morse Taper No.
|
3
|
4
|
4
|
5
|
Vertical Adjustment Of Arm
|
15"
|
18"
|
21"
|
24"
|
Over All Height
|
60"
|
70"
|
80"
|
90"
|
Arm Tilt Any Angle Up To
|
90"
|
90"
|
90"
|
90"
|
Floor Space Required
|
36" * 21"
|
44" * 25"
|
55" * 30"
|
61" * 32"
|
Electrical Motor Required
|
1 H.P.
|
2 H.P.
|
3 H.P.
|
5 H.P.
|
